Detection Model
|
Retro-Reflection
|
|
Item No.
|
N.C.
|
IR-3000L
|
|
N.O.
|
IR-3000D
|
|
Sensing Range
|
30 meters
|
|
Input Voltage
|
DC 12-240V +/- 10% or AC 24-240V +/- 10%
|
|
Response Time
|
15ms
|
|
Emitting Element
|
IR LED
|
|
Operation Indicator
|
Yellow LED (turn on when beam is broken)
|
|
Dimensions
|
21mm(w) x 55mm(h) x 50mm(d)
|
|
Current Consumption
|
2VA Max.
|
|
Output Method
|
Relay output
|
|
Contact Current
|
3A / 250VAC
|
|
Illumination
|
Lamplight<10,000 Lux ; Sunlignt<30,000 Lux
|
|
Connection Method
|
Cable lead wires:Brown/Blue/White/Black/Gray
|
|
Noise Resistance
|
1500Vp-P / 1uS
|
|
Surge Resistance
|
2KV / 1uS
|
|
Vibration Resistance
|
10-55Hz / 1.5mm, 2 Hours In X.Y.Z. Phase
|
|
Housing Material
|
Case: Intensive ABS; Lens:PC
|
|
Operating Temp.
|
-20°С~60°С
|
|
Safety Standard
|
CE
|
